Marubeni Citizen-Cincom debut many new models at #IMTS 2014 and #PMTS 2015. One of the most impressive and Industry defining technologies was shown in the BNE51-MSY. Making its debut at #IMTS2014 and again at PMTS2015, the Miyano BNE51-MSY takes turret Lathe technologies to the next level with innovative design and Miyano new Cincom Control technology. In short, the BNE51-MSY is turret lathe with sub spindle design characteristics and control technology that enables 3 tools in the cut at one time with a two turret machine. New BNE51-MSY design and control supports many features -like Multi Axis Super Imposition by G-code- typically found only in Swiss type machines.
The machine was a home run hit with –AE, Programmers and Operators- at the show who know both Swiss and Turret lathes programming and processing. Mitsubishi Materials provided tools shown in the demo. For the video, holes produced with the MVX drill were -drilled 1st with coolant and then re-filmed in proper machine sequence running dry.
For more information on technology shown in the video contact Marubeni Citizen-Cincom Inc. representative or visit their web site at: https://www.marucit.com/
Mitsubishi Materials tooling list:
Cut-Off: GYHRUS12C00-M25R (Holder), GYHRUS12C00-M25R (Blade), GY2G0400G040N-MF/VP20RT (Insert)
OD Turning: DCLNR-124 and CNMG432MM/MC7015 insert
Indexable Drilling: MVX0875x2C100 and MVX0687x2C100
Grove Turn: GYHRUS12C00-M25R (Holder), GYM25RA-F06 (Blade), GYM0300F040N-MS/VP20RT (Insert)
OD Threading: MMTER-123 (Holder), MMT16ER120UN-S/VP15TF (Insert)
ID Threading: MMTIR103-0.75-1.5 C (ID Bar), MMT16IR160UN/VP15TF Insert
Solid Carbide Drill: MVE0397x02S060/DP1020
Face Mill Lower Turret: ASX445R0205, SEMT13T3AGSN-JM/MP7140
Face Mill Upper Turret: WSX445R0205, SNMU140812ANER-M/MP7130
Mitsubishi Brochures in .pdf format are available for download at https://www.mitsubishicarbide.com/mmus/en/product/catalog/index.html
Experience Mitsubishi Carbide’s Patented Online Catalog at https://www.mitsubishicarbide.net/mmus/en/catalogue/index.html
Secure technical inquires can be submitted to Mitsubishi Materials at https://www.mitsubishicarbide.com/mailform/mmus/en/literature/form.html
Tooling questions please contact:
Technical Support at 1-800-486-2341
or
Email MarketingServices@mmus.com
Thank you for taking the time to view this video.
